At Hazlewood Fasteners in Canberra, Australia, our Monel stud bolts stand as unwavering defenders of structural certainty in the world’s most hostile environments. These precision-engineered fasteners are crafted for situations where corrosion never rests, pressure is relentless, and mechanical demands border on extreme. Built with discipline and driven by engineering excellence, our Monel stud bolts reinforce critical systems with silent, ironclad strength. When industries require absolute resilience — whether at sea, in chemical processing lines, or inside high-temperature industrial machinery — Hazlewood’s Monel stud bolts hold firm, delivering steadfast security and performance that refuses to yield.
Monel stud bolts are forged from a high-performance nickel-copper alloy, primarily nickel with substantial copper content and trace elements such as iron and manganese for reinforcement. This metallurgical formula produces exceptional corrosion resistance — especially against saltwater, acids, and alkaline conditions — while maintaining remarkable tensile strength and toughness. Immune to chloride stress cracking and capable of withstanding thermal extremes, Monel sustains mechanical integrity under severe vibration, shock, and continuous load. Precision threading ensures reliable torque transfer and dependable clamping force, making these bolts a formidable solution for punishing industrial environments.
| Element | Content (%) |
| Nickel, Ni | 63.00 min |
| Silicon, Si | 0.5 max |
| Carbon, C | 0.3 max |
| Sulphur, S | 0.024 |
| Copper, Cu | 28-34 |
| Iron, Fe | 2.5 max |
| Manganese, Mn | 2 max |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 35,000 , MPa – 240 | Psi – 80,000 , MPa – 550 | 40 % |
| Grade | Monel 400 (UNS N04400) |
| Specifications | ASTM F467 /ASME SF467 |
| Dimension | ASTM, IS, BS and all International Standards |
| Length | 3mm to 200mm |
| Size | M02 to M33 | Custom Sizes |
| Types | Threaded Rod, Class A double ended stud, Tie Rod, Double Ended Stud, Stud Bolts, Bronze Hex Studs, Threaded Studs etc |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Monel stud bolts excel in mission-critical environments where corrosion, stress, and temperature extremes challenge conventional fasteners. Marine and offshore structures rely on them to survive salt-laden atmospheres, turbulent tides, and deep-sea pressures. Chemical and petrochemical processing facilities deploy them in piping systems, flanges, and pressure vessels exposed to aggressive chemicals and high heat. Power plants, desalination units, and refinery equipment depend on their enduring strength in corrosive setups. From aerospace systems and naval infrastructure to pumps, valves, and heat exchangers, Monel stud bolts deliver uncompromising reliability — securing vital machinery and structures where failure is simply not allowed.
Monel stud bolts in sheatal fasteners are carefully installed to maintain premium quality and integrity. Each bolt is carefully wrapped with protective coatings and secured to the durable, tamper-resistant material to prevent damage during transport. We offer flexible packaging, including standard sized boxes and secure containers, customized to your specific needs. Our comprehensive packaging solutions ensure that Monel Stud Bolts arrive in perfect condition, ready for immediate installation and optimal performance in demanding applications.
